Overview
The PTI68NL/PII6INL series of SMT power inductors features a shielded drum core design with a maximum height of 4.5mm and a footprint of 12.2mm x 12.2mm.
Key Features
Operating temperature range: -40°C to +130°C
Current rating: up to 14A
Inductance range: 0.32μH to 750μH
RoHS compliant
Electrical Specifications
Part numbers, inductance, DCR, saturation current, and heating current are listed in the datasheet.
Mechanical Specifications
Dimensions, weight, and suggested pad layout are provided.
Additional Information
Temperature rise, core loss, and estimated temperature rise calculations are discussed, along with notes on testing and application considerations.
